Flora RGB Smart Neo Pixel version 2 - Pack of 4

MORE VIEWS:

Flora RGB Smart Neo Pixel version 2 - Pack of 4
Flora RGB Smart Neo Pixel version 2 - Pack of 4
Flora RGB Smart Neo Pixel version 2 - Pack of 4

Flora RGB Smart Neo Pixel version 2 - Pack of 4

These daisy chain-able RGB LED pixels were designed specifically with wearables in mind! … More>

$7.99

This item is currently out of stock.

CLICK HERE to be notified when this is back in stock

Product #: MKAD59

What's a wearable project without LEDs?

Flora RGB Smart Neo Pixel version 2 - Pack of 4 . These daisy chain-able RGB LED pixels were designed specifically with wearables in mind! Each LED has a constant current driver and controller built right in, giving you 24-bit color with PWM brightness control. Each pixel only requires 3 connections; positive, negative, and i2c. An Flora can drive up to 500 of these at 30FPS before running out of RAM.



Each order comes with 4 individually controllable pixels. They are the high speed, 800khz version and are not compatible with the V1 400khz version.
Dimensions: 0.4" x 0.5" x 0.1" / 10.2mm x 12.7mm x 2.5mm 0.5" (12.5mm) diameter circle PCB, 0.1" (2.5mm) total thickness 800 KHz speed protocol Chainable design 5-9VDC power (can run at 3.5V but color will be dimmed), constant current 18.5mA per LED (~55mA max total per pixel)
